Equipment Description:

New Genie Z-60 Electric Articulating Boom Lift with 4WD, Standard FLA flooded lead acid battery, 6' dual entry steel platform, dual axis joystick steering, 5' Jib, AC Power cord to platform, Drive enable system, Horn, Lift Guard Contact Alarm, Platform load sense system, Proportional controls, Self-leveling platform, Travel alarm package: flashing beacons, descent, travel and tilt alarms, Telematics ready, Chassis tilt drive function cut-out, Dual parallelogram lift linkage, Rough Terrain Foam filled non-marking tires, plus a beautiful finish! (STOCK PHOTOS, OTHER OPTIONS AVAILABLE)

DC Power Genie Z-60 DC Articulated Boom

Call for priceNew

Contact Information

Western Material Handling
1113 N. College Ave
Ft Collins, Colorado 80524

CONTACT :

Dennis Firkins

PHONE :

303-625-6477

FAX :

970-224-5471

Stock #:

CHECK AVAILABILITY

Manufacturer:

Genie

MODEL #:

Z-60 DC

Drive:

4WD

SUBCATEGORY:

Articulated Boom

Height:

65 ft

FUEL:

DC Power

CONDITION:

New

LOCATION:

Colorado [80022]

DESCRIPTION:

NEW GENIE Z-60 ELECTRIC ARTICULATING BOOM LIFT 48V

Equipment Description:

This product was posted on 11/14/2024

Overview
- Model: Genie Z-60 DC
- Type: Articulating Boom Lift
- Power Source: Electric
Dimensions
- Height - Stowed: 8 ft 2 in (2.49 m)
- Length: 25 ft 1 in (7.64 m)
- Width: 8 ft 2 in (2.49 m)
- Wheelbase: 8 ft 1 in (2.46 m)
- Ground Clearance: 1 ft (0.30 m)
Working Heights and Reach
- Maximum Working Height: 65 ft 7 in (20.16 m)
- Maximum Platform Height: 59 ft 7 in (18.16 m)
- Horizontal Reach: 36 ft 7 in (11.15 m)
- Up and Over Clearance: 24 ft 3 in (7.39 m)
Lift Capacity
- Maximum Lift Capacity: 500 lbs (227 kg)
Platform
- Platform Size: 8 ft x 3 ft (2.44 m x 0.91 m)
- Platform Rotation: 160°
- Jib Length: 5 ft 6 in (1.68 m)
- Jib Range of Motion: 70° (+70°/-60°)
Performance
- Drive Speed - Stowed: 4.0 mph (6.44 km/h)
- Drive Speed - Raised: 0.67 mph (1.08 km/h)
- Gradeability - 2WD: 30%
- Gradeability - 4WD: 45%
- Turning Radius - Inside: 8 ft 2 in (2.49 m)
- Turning Radius - Outside: 16 ft 8 in (5.08 m)
Power
- Power Source: 80 V AC
- Battery Capacity: 520 Ah
- Charger: 15 kW 3-phase electric motor
Weight
- Machine Weight: 16,600 lbs (7,530 kg)
Tires
- Tire Type: Foam-filled
- Tire Size: 355/55D625
Additional Features
- Emission-free operation
- Low noise levels
- Efficient 4WD system
- Regenerative braking
