2021 Rightline LCM140- AP-1B

carton clamps

$5,500 USD
Instant Quote Eligible Listing - CLICK HERE!
ATTACHCO
CONTACT INFO
Name:
Andrew Forde
Phone:
Website:

ADDRESS
ATTACHCO
665 W Cowles St
Long Beach California 90813
ATTRIBUTES
STOCK #:
CC-342
YEAR:
2021
Manufacturer:
MODEL #:
CAPACITY:
2500
CLASS:
II
SUBCATEGORY:
SERIAL #:
214158
CONDITION:
Used
LOCATION:
California [90813]
POST DATE:
11/11/2024
Equipment Description
Arm Height 54.0" Arm Length 48.0" Arm Thickness 2.13" at pivot Capacity 2500 lbs. @ 24 in. load center Frame Width 48.0" Horizontal Center of Gravity 16.8" Hook Spread 29.0" Hydraulic Features: Non Side Shifting Hydraulic Features Non Side Shifting Hydraulic Features Flow Divider Lateral Center of Gravity Not Applicable Lost Load 5.88" Lower Hook quick disconnect Maximum Flow 20.0 gpm Maximum Pressure 2400 psi Max Lateral Offset Not Applicable Minimum Flow 12.0 gpm Mounting Size ITA II Opening Range 29.88"- 100.5" Option armor plate system Recommended Flow 16.0 gpm Recommended Pressure 2250 psi Total Weight 1880 lbs Vertical Center of Gravity 14.9"
  • Model Number: LCM140-AP-1B
  • Manufacturer: Rightline
  • Type: Attachment
  • Subtype: Carton Clamps
  • Capacity
    • Load Capacity: 3,080 lbs
  • Dimensions
    • Frame Width: Approximately 51 inches
    • Height: Approximately 39 inches
    • Arm Length: Varies
  • Performance
    • Opening Range: Approximately 15.7 inches to 65 inches
    • Clamp Force: Adjustable
  • Material/Construction
    • Material: High-strength steel
    • Finish: Powder-coated
  • Hydraulics
    • Cylinder Type: Double acting
    • Hydraulic Options: Integral sideshift available
  • Weight
    • Attachment Weight: Approximately 1,146 lbs
  • Features
    • Non-split arm design
    • Quick change arm pads
    • Low profile frame
