Equipment Description:

New Genie S-85 XC Telescopic Boom Lift with 74 hp, 55 kW, Deutz TD2.9L - Turbo Diesel - T4f, Anti-restart engine protection, Auto engine fault shutdown, In cylinder glow plug (diesel only), 6ft/1,83m dual-entry platform with side swing gate, 8ft/2,44m tri-entry platform with side swing gate, Dual axis joystick steering, 660lb/300kg & 1000lb/454kg dual load capacity with automatic envelope control, Drive enable system, Horn, Lift Guard Contact Alarm, Lift Tools Work Tray, Platform load sense system, Proportional controls, Self-leveling platform, Lift Connect Telematics, Telematics-ready, Rough terrain, foam-filled tires, 2 speed wheel motors, Active oscillating axle, Alarm package: includes flashing beacon and travel alarm, Chassis tilt lift and drive function cut-out, Descent - tilt and motion alarm, Dual battery system, Hydraulic oil cooler, plus a beautiful finish! (STOCK PHOTOS, OTHER OPTIONS AVAILABLE)

Diesel Genie S-85 XC Telescopic Boom

Call for priceNew

Contact Information

Western Material Handling
1113 N. College Ave
Ft Collins, Colorado 80524

CONTACT :

Dennis Firkins

PHONE :

303-625-6477

FAX :

970-224-5471

Stock #:

CHECK AVAILABILITY

Manufacturer:

Genie

MODEL #:

S-85 XC

Drive:

4WD

SUBCATEGORY:

Telescopic Boom

Height:

91 ft

FUEL:

Diesel

CONDITION:

New

LOCATION:

Colorado [80022]

DESCRIPTION:

NEW GENIE S-85 XC TELESCOPIC BOOM LIFT DIESEL

Equipment Description:

This product was posted on 11/9/2024

Working Height
- Maximum Working Height: 91 ft 8 in (28 m)
Platform Height
- Maximum Platform Height: 85 ft 8 in (26.2 m)
Maximum Horizontal Reach
- Maximum Horizontal Reach: 76 ft 6 in (23.3 m)
Up and Over Clearance
- Up and Over Clearance: 34 ft 9 in (10.6 m)
Lift Capacity
- Unrestricted Lift Capacity: 660 lbs (300 kg)
- Restricted Lift Capacity: 1,000 lbs (454 kg)
Platform Dimensions
- Platform Length: 3 ft (0.91 m)
- Platform Width: 8 ft (2.44 m)
Machine Width and Height
- Machine Width: 8 ft 2 in (2.5 m)
- Machine Height: 10 ft 1 in (3.07 m)
Wheelbase
- Wheelbase: 9 ft (2.74 m)
Turntable Rotation
- Turntable Rotation: 360° Continuous
Jib
- Jib Length: 5 ft (1.52 m)
- Jib Articulation: 135° (+78°/-57°)
Drive Speed
- Stowed: 2.5 mph (4.02 km/h)
- Raised: 0.68 mph (1.1 km/h)
Gradeability
- Gradeability: 40%
Power Source
- Engine: Deutz D2.9 L4 4-cylinder diesel, 74 hp (55 kW) Tier 4 Final
Fuel Tank Capacity
- Fuel Tank Capacity: 50 gal (189.27 L)
Weight
- Machine Weight: 42,900 lbs (19,459 kg)
