Equipment Description:

New Genie GTH-844 Telehandler with 8K Capacity Less de-rate, Approx. 44' max fork height, Cab ROPS/FOPS, enclosed cab: AC, heater, defrost, wipers, washer, split door, Adjustable suspended seat, Backup alarm, Full gauge cluster with engine diagnostics, Fully proportional boom and auxiliary hydraulic controls, Machine level indicator, 74 hp - Deutz TCD 3.6 - T4f, Side-mounted engine, Powershift transmission (PS) 3-speed, Telematics-ready, 3-mode steering (2-wheel, 4-wheel and crab) with limited slip front differential, Cold start intake glow plugs, Full time 4WD with front limited slip differential (LSD), Internal multiple wet disc brakes, Genie manual Quick-Attach (QA) system, Boom angle indicator, Lifting shackle at boom tip, Self-leveling fork frame, plus a beautiful finish! (STOCK PHOTOS, OTHER OPTIONS AVAILABLE)

Diesel Genie GTH-844

Call for priceNew

Contact Information

Western Material Handling
1113 N. College Ave
Ft Collins, Colorado 80524

CONTACT :

Dennis Firkins

PHONE :

303-625-6477

FAX :

970-224-5471

Stock #:

CHECK AVAILABILITY

Manufacturer:

Genie

MODEL #:

GTH-844

POWER:

Diesel

Height:

44 ft

CAPACITY:

8000

MAX FORWARD REACH:

28.2

CONDITION:

New

LOCATION:

Colorado [80022]

DESCRIPTION:

NEW GENIE GTH-844 8K TELEHANDLER DEUTZ DIESEL 4WD CRAB

Equipment Description:

This product was posted on 11/9/2024

Dimensions
- Overall Length: 243 in (6,172 mm)
- Overall Width: 96 in (2,438 mm)
- Height to Top of Cab: 101 in (2,565 mm)
- Wheelbase: 117 in (2,972 mm)
- Ground Clearance: 15 in (380 mm)
Performance
- Maximum Lift Height: 44 ft (13.41 m)
- Max Forward Reach: 28 ft 2 in (8.59 m)
- Lift Capacity: 8,000 lbs (3,629 kg)
- Drive Speed - Maximum: 18 mph (29 km/h)
- Turning Radius (outside): 13 ft 4 in (4.06 m)
Engine
- Engine Model: Diesel - Deutz TCD 3.6 L4 Tier 4 Final
- Power: 100 hp (74.6 kW)
- Fuel Tank Capacity: 30.9 gal (117 L)
Hydraulics
- Hydraulic System Pressure: 3,625 psi (250 Bar)
- Hydraulic Reservoir: 39 gal (148 L)
Brakes
- Service Brakes: Hydraulically actuated, internal wet disc brakes on front axle
- Parking Brake: Spring-applied hydraulic release on front axle
Operational Data
- Operating Weight: 22,600 lbs (10,251 kg)
- Drawbar Pull: 24,000 lbs (10,886 kg)
- Auxiliary Hydraulics Flow: 26.4 gal/min (100 L/min)
