Equipment Description:

New Genie GTH-636 Telehandler with 6K Capacity Less de-rate, Approx. 36' max fork height, Cab ROPS/FOPS, enclosed cab: AC, heater, defrost, wipers, washer, split door, Adjustable suspended seat, Backup alarm, Full gauge cluster with engine diagnostics, Fully proportional boom and auxiliary hydraulic controls, Machine level indicator, 74 hp, Deutz TCD 3.6, T4f, Side-mounted engine, Powershift transmission (PS) 3-speed, Telematics-ready, 3-mode steering (2-wheel, 4-wheel and crab) with limited slip front differential, Cold start intake glow plugs, Full time 4WD with front limited slip differential (LSD), Internal multiple wet disc brakes, Genie manual Quick-Attach (QA) system, Boom angle indicator, Lifting shackle at boom tip, Self-leveling fork frame, plus a beautiful finish! (STOCK PHOTOS, OTHER OPTIONS AVAILABLE)

Diesel Genie GTH-636

Call for priceNew

Contact Information

Western Material Handling
1113 N. College Ave
Ft Collins, Colorado 80524

CONTACT :

Dennis Firkins

PHONE :

303-625-6477

FAX :

970-224-5471

Stock #:

CHECK AVAILABILITY

Manufacturer:

Genie

MODEL #:

GTH-636

POWER:

Diesel

Height:

36 ft

CAPACITY:

6000

MAX FORWARD REACH:

21.11

CONDITION:

New

LOCATION:

Colorado [80022]

DESCRIPTION:

NEW GENIE GTH-636 6K TELEHANDLER DEUTZ DIESEL 4WD CRAB

Equipment Description:

This product was posted on 11/9/2024

Engine

Make: Deutz
Model: TD 2.9 L4
Gross Power: 74 hp (55 kW)
Tier: Tier 4 Final

Dimensions

Length (stowed): 191 in (4.85 m)
Width: 81 in (2.06 m)
Height: 98 in (2.49 m)
Wheelbase: 115 in (2.92 m)
Ground Clearance: 15 in (0.38 m)

Performance

Maximum Lift Capacity: 6,000 lbs (2,722 kg)
Maximum Lift Height: 36 ft (11 m)
Maximum Forward Reach: 21 ft 11 in (6.68 m)
Top Travel Speed: 15 mph (24 km/h)

Operational

Operating Weight: 15,512 lbs (7,036 kg)
Fuel Capacity: 30 gal (114 L)

Chassis

Steering Type: 4-Wheel
Tire Type: Foam-filled

Hydraulic System

Pump Type: Load Sensing Piston
Hydraulic Flow: 24 gal/min (90.8 L/min)

Transmission

Transmission Type: Powershift
Number of Speeds: 3-speed forward and reverse
