2024 Diesel Hyundai 25D-9V Pneumatic Tire 4 Wheel Sit Down

Call for priceNew
Contact Information
CONTACT :
Sales Dept.
PHONE :
FAX :
Stock #:
HYU508
YEAR:
2024
Manufacturer:
MODEL #:
CAPACITY:
5000
FUEL:
Diesel
MAST TYPE:
Three Stage
MAST HEIGHT:
86 / 185 in
SIDE SHIFTER:
Yes
CONDITION:
New
HOUR METER:
2
LOCATION:
DESCRIPTION:
New Arrival!
Equipment Description:
Updated Pictures To Follow!!
  • Engine
    • Model: Kubota V3307
    • Type: Diesel, 4-Cylinder, Turbocharged
    • Power: 70 HP (52 kW) at 2,400 rpm
    • Displacement: 3.3 liters
    • Fuel Tank Capacity: 70 liters
  • Performance
    • Load Capacity: 2,500 kg
    • Max Travel Speed: 18.5 km/h
    • Lifting Speed (with Load): 500 mm/sec
    • Lowering Speed (with Load): 450 mm/sec
  • Dimensions
    • Overall Length: 3,680 mm
    • Overall Width: 1,245 mm
    • Overall Height (Mast Lowered): 2,160 mm
    • Wheelbase: 1,600 mm
    • Ground Clearance: 105 mm
  • Weight
    • Service Weight: 3,850 kg
  • Tires
    • Front: 7.00-12-12PR
    • Rear: 6.00-9-10PR
  • Transmission
    • Type: Powershift
    • No. of Gears: 1 forward / 1 reverse
  • Brakes
    • Service Brake: Hydraulic
    • Parking Brake: Mechanical, Hand Operated
  • Hydraulics
    • Hydraulic System Pressure: 210 bar
    • Hydraulic Oil Tank Capacity: 53 liters
  • Mast
    • Max Fork Height: 3,000 mm
    • Mast Tilt Angle: 6° forward / 12° backward
  • Operator's Area
    • Cabin: Open/Option for Enclosed
    • Steering: Fully Hydrostatic Power Steering
    • Adjustable Seat: Yes
