2024 Diesel Hyundai 30D-9 Pneumatic Tire 4 Wheel Sit Down

Call for priceNew
Contact Information
CONTACT :
Jay Handra
FAX :
Stock #:
H0256
YEAR:
2024
Manufacturer:
MODEL #:
CAPACITY:
6000
FUEL:
Diesel
MAST HEIGHT:
86 / 185 in
SERIAL #:
HHKHHN13HF0004130
SIDE SHIFTER:
Yes
CONDITION:
New
HOUR METER:
2
Equipment Description:
In Stock and Ready for Delivery Specifications:Year: 2024Make: HyundaiModel: 30D-9Lowered Mast: 86 inchesRaised Mast: 185 inchesFuel: DieselHours: 2Attachments: Cascade SideshiftTire Type: PneumaticFork Size: 2X5X48 IIICapacity: 6,000 lbsValves: 3 SpoolStock Number: H0256Serial Number: HHKHHN13HF0004130Enhance your operations with this well-maintained, reliable forklift. Contact Trupar America today for more details and to arrange delivery.
  • Model: Hyundai 30D-9
    • Type: Diesel Forklift
  • Engine Specifications
    • Engine Model: Kubota V3307
    • Rated Power: 55.4 kW at 2,300 RPM
    • Max Torque: 265 Nm at 1,600 RPM
    • No. of Cylinders: 4
  • Dimensions & Capacity
    • Overall Length: 3,790 mm
    • Overall Width: 1,240 mm
    • Overall Height: 2,125 mm (Overhead Guard)
    • Wheelbase: 1,700 mm
    • Ground Clearance: 140 mm
  • Performance
    • Load Capacity: 3,000 kg
    • Max Travel Speed: 18.5 km/h
    • Lifting Speed (Loaded): 530 mm/s
    • Lifting Speed (Unloaded): 650 mm/s
    • Gradeability: 35% (Full Load)
  • Weight
    • Service Weight: 4,590 kg
  • Brakes
    • Service Brake: Hydraulic
    • Parking Brake: Mechanical, Hand Lever Actuated
  • Tires
    • Front: 7.00-12-12PR
    • Rear: 6.00-9-10PR
  • Steering System
    • Type: Hydrostatic Power Steering
  • Fuel Tank
    • Fuel Tank Capacity: 60 liters
  • Hydraulic System
    • Hydraulic System Pressure: 180 kgf/cm²
  • Mast
    • Lift Height: 3,000 mm
    • Free Lift: 145 mm
    • Forward Tilt: 6 degrees
    • Backward Tilt: 12 degrees
