2020 Electric BYD ECB-25 Electric 4 Wheel Sit Down

$18,000 USD
Contact Information
Dillon Toyota Lift
2640 California Avenue
Salt Lake City, Utah 84104
CONTACT :
Dillon Toyota Lift
PHONE :
Stock #:
BYD15547
YEAR:
2020
Manufacturer:
MODEL #:
CAPACITY:
5400
FUEL:
Electric
MAST TYPE:
Three Stage
MAST HEIGHT:
86 / 189 in
SERIAL #:
0701190574
SIDE SHIFTER:
Yes
CONDITION:
Used
HOUR METER:
4433
LOCATION:
Equipment Description:
Class II carriage, single ac drive motor, 43kwh (540ah), finger tip controls, suspension seat, orange belt, inter-lock, 48" LBR, rear blue light, led lights, rear light bar, amber strobe, clipboard holder, usb charger, 3 aux power plugs
  • Performance
    • Load Capacity: 2,500 kg
    • Lift Height: 3,000 mm
    • Travel Speed (loaded/unloaded): 15 km/h / 16 km/h
    • Lift Speed (loaded/unloaded): 300 mm/s / 470 mm/s
    • Lowering Speed (loaded/unloaded): 300 mm/s / 280 mm/s
    • Gradeability (loaded/unloaded): 15% / 20%
  • Dimensions
    • Overall Length: 3,634 mm
    • Overall Width: 1,226 mm
    • Overall Height (mast lowered): 2,130 mm
    • Overall Height (mast extended): 4,150 mm
    • Turning Radius: 2,155 mm
    • Fork Dimensions: 1,070 mm x 100 mm x 45 mm
  • Power
    • Battery Voltage: 80V
    • Battery Capacity: 540 Ah
    • Drive Motor Power: 7.5 kW
    • Lift Motor Power: 14 kW
  • Tires
    • Front Tires: Solid, 21 x 8-9
    • Rear Tires: Solid, 16 x 6-8
  • Weight
    • Total Weight: 4,150 kg
  • Additional Features
    • Electric Power Steering
    • Regenerative Braking System
    • LCD Display for Instrumentation
    • Adjustable Steering Column
