Equipment Description
Engine: Volvo 6 cylinder turbocharged diesel Tier 4 compliant model TAD1250VE
Transmission is a 4 speed fwd and rev – Dana TE32000
Planetary differential with wet disc brakes
Fully enclosed cab with heater, wipers, defroster, full instrumentation, seat belts
2 stage Hi visibility mast 218.5” overall lowered height x 236” maximum fork height
Standard Kalmar design carriage with hydraulic fork positioning forks and sideshifting forks (This provides nearly full capacity with sideshift)
Forks are 5.3” thick x 11.8” wide x 120” long with outside edge radius
Tires are 18.00x33 Pneumatic
Overall length rear of counterweight to face of forks 313” + 120” long forks
Overall width across drive tires 164”
Overall height ground to top of cab 151”
Wheelbase 217”
Outside turning radius 320.9”
Service weight fully assembled and filled with fluids 135,938 Lbs
