2015 JLG 1255

diesel

Call for price
Illinois Lift Equipment
CONTACT INFO
Name:
John Hellyer
Phone:

ADDRESS
Illinois Lift Equipment
640 Industrial Dr
CaryIllinois 60013
ATTRIBUTES
STOCK #:
13708
YEAR:
2015
Manufacturer:
MODEL #:
POWER:
Diesel
Height:
55 ft
CAPACITY:
12000
CONDITION:
Used
LOCATION:
Illinois [60013]
DESCRIPTION:
12000LB CAPACITY 55' MAX LIFT HEIGHT 4X4X4
POST DATE:
3/7/2025
Equipment Description
12000LB CAPACITY 55' MAX LIFT HEIGHT 4X4X4 PNEUMATIC TIRES CUMMINS DIESEL ENGINE OUTRIGGERS / STABILIZERS HYDRAULIC LEVELING FORKS AS SHOWN
  • General Specifications
    • Model Number: 1255
    • Manufacturer: JLG
    • Type: Telehandler
  • Dimensions
    • Overall Length (without forks): 20 ft 3 in
    • Overall Width: 8 ft 6 in
    • Overall Height: 8 ft 6 in
    • Wheelbase: 12 ft 1 in
    • Ground Clearance: 1 ft 6 in
  • Performance
    • Max Lift Capacity: 12,000 lbs
    • Max Reach: 42 ft
    • Max Forward Reach: 35 ft
    • Turning Radius (outside): 14 ft 1 in
    • Travel Speed: 20 mph
  • Engine
    • Make: Cummins
    • Type: Turbo Diesel
    • Power: 130 hp
    • Fuel Tank Capacity: 44 gal
  • Tires
    • Tire Size: 15.5-25
    • Tire Type: Pneumatic
  • Hydraulic System
    • Hydraulic Power: 45 gal/min
    • Hydraulic System Pressure: 3,500 psi
  • Weights
    • Operating Weight: 36,070 lbs
    • Counterweight: Integral
