Equipment Description:

2023 Electric Clark ESX15S Electric Stand Up End Control (Docker)

Name: 2023 Clark ESX15S
Brand: Clark
SKU: 312220
Price: 32300 USD
Availability: InStock

$32,300 USDNew

Contact Information

C & B Material Handling LLC
5875 State St
Bettendorf, Iowa 52722

CONTACT :

Dennis Marriott

PHONE :

Stock #:

312220

YEAR:

2023

Manufacturer:

MODEL #:

CAPACITY:

3000

FUEL:

Electric

SUBCATEGORY:

MAST TYPE:

Three Stage

MAST HEIGHT:

188 in

SERIAL #:

ESX250-1259-9706KY

SIDE SHIFTER:

Yes

CONDITION:

New

HOUR METER:

LOCATION:

DESCRIPTION:

36V, NM DRIVES, 42" FORKS

Equipment Description:

This product was posted on 12/12/2024

General Specifications
- Model: ESX15S
- Type: Electric Stand-up Rider Forklift
- Load Capacity: 3,000 lbs (1,500 kg)
- Power Source: Battery
- Operator Type: Stand-up
Dimensions
- Overall Length: 86 inches (2,184 mm)
- Overall Width: 41 inches (1,041 mm)
- Height to Top of Overhead Guard: 89 inches (2,261 mm)
- Wheelbase: 50 inches (1,270 mm)
- Turning Radius: 62 inches (1,574 mm)
Mast Specifications
- Mast Type: 3-Stage
- Lift Height: Up to 221 inches (5,616 mm)
- Lowered Mast Height: 93 inches (2,362 mm)
- Free Lift: 55 inches (1,397 mm)
Performance
- Travel Speed: Up to 7.5 mph (unloaded)
- Lift Speed: 90 feet per minute (unloaded)
- Lowering Speed: 100 feet per minute (loaded)
- Gradeability: Up to 15% (loaded)
Battery and Electrical
- Battery Voltage: 36 Volts
- Battery Capacity: 775 Ah
- Electrical System: AC Drive Technology
Wheels and Tires
- Drive Tire: 16 x 5 inches
- Steer Tire: 12 x 5 inches
- Tire Type: Polyurethane
Brakes
- Service Brake: Regenerative
- Parking Brake: Automatic Electric
Additional Features
- AC Controller Technology
- Electronic Power Steering
- Multi-function Display
- Adjustable Armrest and Controls
