2023 Kubota L4802HST Agricultural & Farming

Call for priceNew
Contact Information
New Tec, Inc.
3764 US 75 Ave
Sioux Center, Iowa 51250
CONTACT :
Joe or Marlin
PHONE :
FAX :
Stock #:
0019118
YEAR:
2023
Manufacturer:
MODEL #:
SUBCATEGORY:
SERIAL #:
KBULMCHRHPJG11530
CONDITION:
New
LOCATION:
DESCRIPTION:
Tractor, 4WD, Kubota Engine, Gross 48.4 Hp / PTO 39 Hp
Equipment Description:
Foldable ROPS, HST Transmission, R4 Tires
  • Engine:
    • Type: Direct Injection, Vertical, Water-cooled 4-cycle diesel
    • Engine Model: V2403-CR-TIE4
    • Gross HP: 48.4 (36.1 kW)
    • Net HP: 47.3 (35.3 kW)
    • Total Displacement: 148.5 cu.in. (2,434 cc)
    • Rated RPM: 2,600
    • Fuel Tank Capacity: 13.5 gal. (51 L)
  • Transmission:
    • Type: Hydrostatic transmission, 3-range
    • Max Forward Speed: 12.6 mph (20.3 km/h)
    • Max Reverse Speed: 12.0 mph (19.3 km/h)
  • Hydraulics:
    • Pump Capacity (PS): 8.5 gpm (32.2 L/min)
    • Pump Capacity (3-Point Hitch): 5.0 gpm (19 L/min)
    • 3-Point Hitch: Category I
    • Hydraulic Control System: Position control, standard; draft control, optional
    • Lift Capacity at 24 inches behind lift point: 2,760 lbs (1,251 kg)
  • Dimensions:
    • Overall Length (w/o 3P): 123.2 in. (3,130 mm)
    • Overall Width (min. tread): 67.3 in. (1,710 mm)
    • Overall Height (top of ROPS): 97.2 in. (2,470 mm)
    • Wheelbase: 72.8 in. (1,850 mm)
    • Ground Clearance: 13.5 in. (340 mm)
  • Tire Sizes:
    • Standard Front: 9.5-16 R1
    • Standard Rear: 14.9-24 R1
  • Weight:
    • Weight with ROPS: 3,505 lbs (1,590 kg)
  • PTO:
    • Type: Live-independent, hydraulic
    • Rear PTO: 540 RPM
    • Mid PTO: Optional
  • Steering:
    • Type: Hydrostatic power steering
