2016 Diesel Genie ZX135/70

Chicago Industrial Equipment Rockdale, Illinois (289 miles away)

Overview
Spec Sheet
Shipping/Freight

2016 Genie ZX135/70

Diesel Telescopic Boom

Call for price
CONTACT INFO
Name:
Justin Cyrnek
Phone:

ADDRESS
Chicago Industrial Equipment
600 Oakwood Ct
Rockdale, Illinois 60436
ATTRIBUTES
STOCK #:
CR-Z1304
YEAR:
2016
Manufacturer:
MODEL #:
Drive:
4WD
SUBCATEGORY:
Height:
1620 ft
FUEL:
Diesel
SERIAL #:
ZX13516-2785
CONDITION:
Used
LOCATION:
POST DATE:
11/5/2024
Equipment Description
**RENTAL ONLY** 4X4 DEUTZ DIESEL 135′ PLATFORM HEIGHT 141′ WORKING HEIGHT 69′ HORIZONTAL REACH 600 LB CAPACITY EXTENDABLE AXLE FOAM FILLED TIRES ARTICULATING READY TO WORK CONTACT US FOR COMPETITIVE FREIGHT RATES!
  • General Specifications:
    • Model: Genie ZX135/70
    • Type: Articulated Boom Lift
    • Maximum Working Height: 141 ft (43.15 m)
    • Maximum Horizontal Reach: 69 ft 9 in (21.26 m)
    • Up and Over Clearance: 75 ft 6 in (23.01 m)
    • Platform Capacity: 600 lbs (272 kg)
  • Dimensions:
    • Length - Stowed: 37 ft 7 in (11.46 m)
    • Width - Stowed: 8 ft 2 in (2.49 m)
    • Height - Stowed: 10 ft (3.05 m)
    • Wheelbase: 12 ft 6 in (3.81 m)
  • Drive and Steering:
    • Drive Speed - Stowed: 3.4 mph (5.5 km/h)
    • Drive Speed - Raised: 0.68 mph (1.1 km/h)
    • Steering Type: 4-wheel
    • Turn Radius - Inside: 7 ft 6 in (2.29 m)
    • Turn Radius - Outside: 19 ft 11 in (6.07 m)
  • Power Source:
    • Power Source: Diesel Engine
    • Engine: Deutz TD2.9 L4 74 hp (55.4 kW)
    • Fuel Tank Capacity: 40 gal (151.4 L)
  • Operational Specifications:
    • Gradeability: 45%
    • Platform Rotation: 160 degrees
    • Vertical Jib Rotation: 110 degrees
    • Horizontal Jib Rotation: 400 degrees (non-continuous)
  • Weight:
    • Operating Weight: 44,900 lbs (20,366 kg)
  • Additional Features:
    • Standard 8 ft (2.44 m) platform
    • 4-wheel drive and 4-wheel steer for better maneuverability
    • Oscillating axle for rough terrain
    • AC power to platform
Legal Disclaimer

The specifications provided herein are for informational purposes only and are not guaranteed to be 100% accurate. This tool is currently in beta testing, and while we strive to provide the most accurate and up-to-date information, there may be discrepancies or errors. We strongly recommend that you verify all specifications and details with the manufacturer of the equipment or an authorized dealer. The information presented should not be considered definitive or relied upon as the sole basis for decision-making. In some cases, certain specifications are based on new equipment when shipped from the factory and may have changed over time. For example, masts and forks are routinely changed or updated. Headlights, taillights, and backup alarms are usually included with new equipment, but can be removed over time. Neither the creators of this tool nor any affiliated parties shall be held liable for any inaccuracies, errors, or omissions in the information provided. By using this tool, you acknowledge and agree that you assume all risks associated with the use of the specifications and information provided. For 100% accuracy and the most reliable information, please contact the manufacturer of the equipment or an authorized dealer directly.


1 Review Shipping Dimensions
Schematic for Genie ZX135/70
These dimensions are taken from the base model. If your equipment has been modified, please update the dimensions.
Length
ft in m
Width
ft in m
Height
ft in m
Weight
lbs kg
2 Pickup Location & Delivery Location
Pickup Location
Delivery Location
